ISO2531 Ductile Iron Pipe

Product name:Ductile iron pipe
Size:DN80~2600mm
Material:Ductile Cast Iron GGG50
Pressure:PN10, PN16, PN25,PN40
Class:K9, K8, C25, C30, C40
Length:6m, cut to 5.7m

TEL: +86 18864855351
WhatsApp: +86 18864855351
E-mail: admin@cnzlgt.com
PRODUCT DETAILS
Product nameDuctile iron pipe
Size:DN80~2600mm
Material:Ductile Cast Iron GGG50
Pressure:PN10, PN16, PN25,PN40
Class:K9, K8, C25, C30, C40
Length:6m, cut to 5.7m
Internal Coating:a). Portland cement mortar lining
b). Sulphate Resistant cement mortar lining
c). High-Aluminum cement mortar lining
d). Fusion bonded epoxy coating
e). Liquid epoxy painting
f). Black bitumen painting
External Coating:a). zinc+bitumen(70microns) painting
b). Fusion bonded epoxy coating
c). Zinc-aluminum alloy+liquid epoxy painting
Standard:ISO2531, EN545, EN598, etc
Certificate:CE,ISO9001, SGS,ETC
Packing:Bundles, in bulk, Pack according to customer requirements
Application:

Water supply project, drainage, sewage, irrigation, water pipeline.etc


Ductile Iron Pipe Has Better Mechanical Performance
PerformanceCentrifugal ductile iron pipeGray iron casting pipeSteel pipe
Resistance to tensile stress≥420(Mpa)150~260≥400
Bending strength≥590 (Mpa)200~360≥400
Extensibility   (N/mm2)DN80-1000≥10 DN1200-2200≥7/≥18
Elastic CoefficientApprox.16x104 (%)Approx.11x104Approx.16x104
Hardness≤230 (HB)≤230 (HB)Approx.140
Yield strength(N/mm2)300/
